Explosion Proof Dome Camera
Created with Pixso.

2.2MP 20X High Speed Explosion-protected Explosion Proof Dome Camera

2.2MP 20X High Speed Explosion-protected Explosion Proof Dome Camera

Brand Name: ZUOAN
Model Number: ZAT630-S-IP
MOQ: 1 set
Price: 0-3000 USD
Payment Terms: 100% TT before shipment
Supply Ability: 1000 set per month
Detail Information
Place of Origin:
China
Certification:
CNEX
Type:
Digital Camera
Style:
Dome Camera
Sensor:
CMOS
Technology:
Pan / Tilt / Zoom
Special Features:
Explosion Proof
Ingress:
IP68
Housing:
Stainless Steel 304/316L
Preset Patrol:
128 Points
Network Camera:
2.2MP, 20Xoptical, POE Dome Camera
Weight:
12KG
Packaging Details:
firm carton or wooden box
Product Description

2.2MP 20X High Speed Explosion-protected Explosion Proof Dome Camera



2.2MP 20X High Speed Explosion-protected Explosion Proof Dome Camera 0

Main features:

Explosion proof certification: CNEx10.1061
Crust: Stainless Steel 304, 316L
highest ingress: IP68 rated
double explosion proof marking: Exd II CT6 Gb/Ex tD A21 IP68 T80°C
wide voltage: AC85~265V
net weight: 12 Kg
package dimension: 205*205*445mm
mounted: wall, or ceiling
rotation: horizontal 360 °, vertical 0~-90°
running speed: 0.1-400°/s
preset point: 128/256 points
control: RS485, RJ45, RS232
communication: AV, RJ45, SDI
protocol: TCP/IP/ pelco-d/pelco-p
optional camera insde: analog camera, network camera, HD camera
Input voltage: AC24V/AC220V, AC85-265V


Description:

ZAT630, it is featured as2.2MP 20X high speed stainless steel explosion-protected explosion prood dome camera.  Its explosion proof dome camera housing can fit for 5inch, 6inch high speed camera, . It is fit for the outside and inside.ZAT630 explosion proof dome camera has the features of high speed location and preset accuracy. And double stainless steel shell ensures this device to work regularly even temperature reaches to 60 degree centigrade.the explosion proof housing is a ready-to-use kit, for all brand cctv camera, like SAMSUNG CCTV camera, Hikvision cctv camera, Dahua cctv camera, Geovision cctv camera.

  2.2MP 20X High Speed Explosion-protected Explosion Proof Dome Camera 1

Applications:

With stringent certifications, explosion-proof CCTV housed cameras enable safe, effective surveillance for chemical sites, oil and gas facilities, food processing plants and numerous other hazardous environments. such as Chemical factory, petrochemical processing plant, pharmaceutical plant, Oil refinery plant, Gas station,Oil tank truck, Natural gas project, Marine, offshore/ onshore oil drilling platform, coal mine, Grain storage, winery storage, fertilizer storage ect.



Data sheet:

Model ZAT630-S-IP
Crust stainless steel 304
Camera type

2MP, 20X optical zoom

color min 1.5lux; B&W 0.1Lux

 focal length: 4.7-94mm

Explosion proof certified Exd II CT6 Gb/Ex tD A21 IP68 T80°C
certification No. CNEx15.2504X
Weather proof IP68
Running speed 0.1-400°/S
Running angle horizontal 360 °, vertical - 90~0°
preset point 128 points
function auto scanning, auto cruise, keep watch
power input AC24V, AC220V, AC85-265V
operate temperature

-40~65°C

Control  RS485, Pelco-D / Pleco-P
Signal output RJ45
Netweight 12Kg




Explosion Proof PTZ Speed Dome Camera-ZAT630 series data sheet.pdf



Details images:

   2.2MP 20X High Speed Explosion-protected Explosion Proof Dome Camera 2
