1.3MP Oil Vessel Mounted Mini Explosion Protected Camera With Infrared Lights

Name: 1.3MP Oil Vessel Mounted Mini Explosion Protected Camera With Infrared Lights
Brand: ZUOAN ELECTRIC APPLIANCE CO., LTD.
SKU: ZAF109-S-IP
Price: 600 USD
Availability: InStock

Brand Name:	ZUOAN
Model Number:	ZAF109-S-IP
MOQ:	1 set
Price:	0-600 USD
Payment Terms:	100% TT before shipment
Supply Ability:	1000 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNEX

Type:

Digital Camera

Style:

Mini Camera

Sensor:

CMOS

Technology:

NetWork

Certificate:

CNEX

Ingress:

IP68

Housing:

Stainless Steel 304

Camera:

1.3MP Camera

Weight:

4KG

Infrared Light:

30m Distance

Packaging Details:

firm carton or wooden box

Product Description

1.3MP Oil Vessel Mounted Mini Explosion Protected Camera With Infrared Lights

Description:

ZAF109-S-IP is 1.3MP HD mini explosion proof camera monitoring equipment. It can be applied in the explosive gas automosphere, like zone1 and zone2 withⅡA,ⅡB orⅡC, and in flammable dust environment, like zone 20,zone21 and zone22. ZAF109 isinternally installed with the infrared lamp with 20m viewing distance, which is suitbale for a less scope night vision environment inside and outside. The ex-proof frade and temperature groups all accord with the highest requirements of National standards.

Applications:

oil tank truck, dangerous goods vehicle, oil tanker, or other hazardous area, with flammable substance, like oil, fertilizer, gas, chemical agent, dust, power, fireworks, ect.

1.3MP Oil Vessel Mounted Mini Explosion Protected Camera With Infrared Lights 1

Main features:

ZAF109 mini explosion proof camera has no wiper, but it's window is made of nano glass which has a self- cleaning flunction.

ZAF109 is installed with a 1.3MP HD 1/3" CMOS ICR camera with a high resolution and a function of automatical switching from color to black.

ZAF109 explosion proof marking is Exd and DIP, products can be widely used in Gas zones and Dust zones.

ZAF109 ingress protection is IP68, get the highest protection grade. ZAF109 weight is 4 KG.

1.3MP Oil Vessel Mounted Mini Explosion Protected Camera With Infrared Lights 2

Data sheet:

Model	ZAF109-S
IP rated	IP68
working temperature	-25~65°C
resolution	950TVL / 720P/ 1080P
lens	3.6mm, 4mm, 6mm,12mm,
crust	stainless steel 304
Explosion proof Marking	Exd II CT6 Gb/ Ex tD A21 IP68 T80℃
Explosion proof certification	CNEx16.2526
application	Gas zone 1, 2; dust zone 20, 21,22
working current	≤1000ml
power consumption	≤15W
power	12VDC/POE
infrared light	30meter
netweight	4KG
Overall dimension	144158167mm
cable output	network cable, 2 core power cable
Cable output hole	1 set G3/4 or NPT3/4
