| Place of Origin: | China, Changzhou |
|---|---|
| Brand Name: | ZUOAN |
| Certification: | CNEX |
| Model Number: | ZAF109 |
| Minimum Order Quantity: | 1pcs |
| Price: | USD200-USD500 per set |
| Packaging Details: | Firm carton whitin 1pcs ZAF109, 4.5kg |
| Delivery Time: | 5-8 work days |
| Payment Terms: | Western Union, MoneyGram, L/C, D/A, D/P, T/T,PAYPAL |
| Supply Ability: | 50pcs per week |
| Resolution: | HD-1080p | Camera: | AHD Camera |
|---|---|---|---|
| VIdeo Output: | 1 Analog HD Output | Video Model: | HDTVI |
| Material: | Stainless Steel 316L | Certificate: | Explosion Proof |
| Apply: | Marine, Hazardous Area | Power Supply: | DC12V |
| Power Consumption: | Max 5W | Infrared Lights: | 0-30m |
| Weather Proof: | IP68 | Lens: | 3.6mm |
| Min. Illumination: | 0.001 Lux @(F1.2,AGC ON), 0 Lux With IR | Angle Of View: | 74.6°(3.6mm) |
| Day& Night: | IR Cut Filter With Auto Switch | S/N Ratio: | More Than 62 DB |
| Horizontal Resolution: | 1100TVL | Wide Balance: | More Than 120dB |
| CVBS Output: | 1Vp-p Composite Output(75Ω/BNC) |
HD-1080p TVI Explosion Proof Turret Camera of Marine Stainless Steel 316L
Explosion proof turret camera summary:
ZAF109 model is HD-1080p TVI explosion proof turret camera. Its horizontal resolution reach to 1100TVL. This Explosion proof turret camera video mode is 1channel analog HD output, which follows the HD-TVI standards. This explosion proof turret camera adopts marine corrosion proof stainless steel 316L material, so as to fit for high aggressive area. With explosion proof certificate, this turret camera can also apply for industry hazaroud area, such as oil tank truck, dangerous vehicle, refinery processing line or petroleum factory.
Explosion proof turret camrea features:
Explosion proof turret camera application:
Our HD-1080P TVI explosion proof turret camera is fit for industry area with explosive gas, oil, chemical and powders. With Ex d & Ex tD marking, it can apply for gas zone 1, zone 2; dust zone 21, and zone 22. With stainless steel 316L crust, this explosion proof turret camera can also apply for marine area.
Explosion proof turret camera data sheet down load:
ZAF109 TVI Explosion proof turret camera data sheet.pdf
Explosion proof turret camera specifications:
Certificate
| Certificate Mark | ExdⅡC T6 Gb/ Ex tD A21 IP68 T80℃ |
| Certificate No | CNEx16.2526 |
| Standards | Q/320412 ZAF033-2016 |
Mechanical
| Housing | Stainless steel 304 or 316L |
| IP | IP68 |
| Cable thread hole | 1pcs G3/4 or NPT3/4 |
Electrical
| Voltage | DC12V |
| Power | 5W |
Ambient
| Ambient temperature | -25 to +60℃ |
| Air pressure | 80Kpa to 106Kpa |
| Relative Humidity | ≦95% (no condensation) |
Lights
| Light distance | 0-30m |
Camera
| Image Sensor | 2.0 Mega Progressive Scan CMOS |
| Effective pixel | 1956*1266 |
| Horizontal resolution | 1100TVL |
| Min. Illumination | 0.01Lux @(F1.2, AGC ON) B/W: 0Lux with IR |
| Lens | 3.6mm @ F2.0, view angle:75° (6mm, 8mm, 12mm) |
| Day& Night | Auto ICR |
| Signal | PAL |
| Synchronization | Internal Synchronization |
| HD Video Output | 1 Analog HD output (HD-TVI standard) |
| Video output | 1 Vp-p composite output (75Ω/BNC) |
| SN rate | More than 62 dB |
| Auto gain | Lower/ middle/ high /off |
| Color | Color/ B&W/ IR |
| White balance | ATW/ AWC-SET/ Indoor/ Outdoor/ Manual |
| Private protect | On/off, 8 zones |
| Move detection | On/off, 4 zones |
| BLC | On/off |
| AGC | Support |
| Exposure | Totally exposure/ wide balance |
| Anti-flicker | On/ Off |
| Function | Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM |
General
| Cable | integrated cable |
| Size | 158*144*167mm |
| Weight | 4kg |
| Mounted | wall, pole |
| Wall bracket | ZAZ109B |
Explosion proof turret camera drawings:
Explosion proof turret camera accessories:
ZA-JXD4 Explosion Proof JB ZANXG Exe Flexible Tube
Special order/ requirements
Contact us for special requirements, Email: info@exproofcctv.com
